Product Images
Product
- R11 Auto Reset Relay
- R11-K10A2VN00
Other Images 1
- R11 Auto Reset Relay
- R11-K10A2VN00
Description
operates as easy as a 3-way normally closed, automatic reset pneumatic valve with a detent (BYPASS) feature
Special Features
- Compact size
- Field proven materials of construction
Technical Data
- Size
- Threaded 1 1/2” and 2”
- Temperature Range
- -50°F to 400°F (Varies by Material Selections)
- Body Trim
- 303 Stainless and 316 Stainless (optional)
- Pilot Trim
- 303 Stainless
- Case Internals
- 303 Stainless
- Pressure Rating
- Threaded 6000 psi
- Body
- A105, LF2 (low Temp Option), SST
- Pilot Connection
- 1/4” NPT
- Pilot Body
- Aluminum
- Case
- Aluminum
- Displacer
- PVC (Standard), Acrylic, Stainless
- Supply Pressure
- Vacuum to 150 psi (10.3 bar)
- Pilot Signal Pressure to opne
- 30 psi (2.0 bar)
- Pilot Signal Pressure to close
- 10 psi (.7 bar)
- Operating Temperature
- -20/+180°F (-29/+82°C)
- Cv Factor
- .34
Documents & Downloads
datasheet
R11 Auto Reset Relay
DownloadFurther Product Information
The K-Dyne, Inc. Model R11 pneumatic relay is a compact automatically operated instrument valve that is well suited for the rigors of inland and offshore production control systems. It operates as easy as a 3-way normally closed, automatic reset pneumatic valve with a detent (BYPASS) feature. Its construction makes it ideal for field mounting on actuators, pressure sensors or other control devices.
- Compact size saves space in panel use
- Seals may be maintained without removal of instrumentation connections
- Panel mountable using optional nut (not included with this unit)
- Easily converted to indicating relay in the shop or field
- Field proven materials of construction
- Latch closed design prevents pilot signal from opening relay
- Detent pin for temporary "BYPASS"
